Steel 3.6m High W Section Palisade Fence Powder Coated Pvc Coating
| Place of Origin | China |
|---|---|
| Brand Name | Giant Fence |
| Certification | ISO9001:2001 |
| Model Number | GF080 |
| Minimum Order Quantity | 50sets |
| Price | Negotiable |
| Packaging Details | 1. panels packing with pallet post bulk in the container 2. panel with post all bulk in the container 3. panle with post all packing with pallet |
| Delivery Time | 15-18days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 5000meters per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Palisade Fence | Width | 2750mm Per Bay Or As You Requirement |
|---|---|---|---|
| Height | 1200mm To 3600mm | Pale Type | D Type, W Type, Or Angle Steel Type |
| Head Type | Pointed, Triple Pointed, Rouned, Rouned And Notched, Flat , Star | Pale Thickness | 1.5mm-/3.0mm |
| Angle Rail | 50x50*5mm,40*40*4mm, | RSJ Post | 100*55*3.5mm |
| Fish Plate | 150*30*7mm | Surface Treatment | Galvanized And Powder Coated. |
| Highlight | 3.6m high w section palisade fence,powder coated w section palisade fence,3.6m high metal palisade fencing |
||
Product Description
PVC Coating Steel 3.6M High W Section Palisade Fencing Powder Coated
Product Description
Palisade fencing use as decoration or protection for various facilities in industry, agriculture, infrastructure, transport, etc..
There are "D" and “ W” based on the diferent tops.
'D' Section Palisade
'D' Section refers to the shape of the vertical pale profile, which is best suited to sites requiring a boundary with forbidding appearance and general damage resistance.
'W' Section Palisade
The 'W' Section profile gives extra protection over 'D' Section to the pale fixing on the attack face of the fence
Palisade Fencing Specifications
| fence panel height | 1m-5m |
| fence panel width | 2m-3m |
| pale height | 1m-5m |
| pale width | W pale:62mm,72mm;D pale:65mm;angle steel:40x40mmx3mm |
| pale thicknesd | 1.5-4.0mm |
| top point | three triple point,single point, round point ETC |
| angle rail | 50mmx50mm,63mmx63mm, |
| angle rail thickness | 4mm-6mm |
| I beam post | 100mmx55mmxheight:1.5m-6m,150mmx75mmxheight:3m-6m |
| C post | 125mmx65mmxheight:2.5m-3.5m |
| square post | 70x70mmx3mm,80x80mmx3mm |
UK BS1722 Standard all 2 rails palisade fence bays of 2.75m includes:
- 1 Palisade Fencing Posts
- 17 Palisade Fencing Pales
- 1 Palisade Fencing Top Rail
- 1 Palisade Fencing Bottom Rail
- 2 Palisade Fencing Fish plates
- 4 Palisade Fencing Anti Tamper M12 Bolts
- 34 Palisade Fencing Anti Tamper M8 Bolts
Product process
1. Materials - With the good quality
2. Cutting&punching - To easy welding & assembly
3. Welding&assembly - With professional technicians
4. G rind&polishing - To assure exquisite, bea utiful and durable
5. Sandblasting - To increase adhesion
6. New pretreatment - Cleaning,paint ad hesion, better corrosion protection
7. Powder coating - With good quality powder
8. Coating finished - Provide smooth, lustrous protective finish
9. Ins pection -To assure every product is perfect
10. Packing -To protect the surface from damage
11. Loading -Uso contain as possibler space as much
12. shipping - We accopt apppointed forwarder
